Bearing N 207 NTN
,

Bearing N 207 NTN

₨ 5,150

Availability: 15 in stock

SKU: 0287 Categories: , Brand:

Key Features

Bearing Type: Cylindrical Roller Bearing (N Type, Separable)

Model: N 207

Brand: NTN

Bore Diameter (d): 35 mm

Outer Diameter (D): 72 mm

Width (B): 17 mm

Design: Single-row cylindrical rollers, outer ring with two ribs, inner ring without ribs

Load Ratings: Dynamic ~42.0 kN | Static ~40.0 kN

Material: High-quality alloy steel with pressed steel cage

Radial Internal Clearance: CN (Normal)

Precision Rating: ISO Class 0

Speed Limits: ~9,500 rpm (grease) | ~11,000 rpm (oil)

Temperature Range: –40 °C to +120 °C

Weight: ~0.29 kg

Applications: Electric motors, pumps, gearboxes, compressors, conveyors, and industrial machinery

Product Description

The NTN N 207 Cylindrical Roller Bearing is built to support heavy radial loads while allowing axial displacement of the shaft in one direction. Its N-type configuration features an outer ring with two fixed ribs and an inner ring without ribs, making it suitable for applications subject to shaft expansion or thermal elongation. Constructed from premium alloy steel with a pressed steel cage, the N 207 delivers high performance, smooth operation, and long service life under demanding operating conditions
