Bearing NU 212 NTN
,

Bearing NU 212 NTN

₨ 9,845

Availability: 10 in stock

SKU: 0277 Categories: , Brand:

Key Features

Bearing Type: Cylindrical Roller Bearing (NU Type, Separable)

Model: NU 212

Brand: NTN

Bore Diameter (d): 60 mm

Outer Diameter (D): 110 mm

Width (B): 22 mm

Design: Single-row cylindrical rollers, separable inner ring, outer ring with two ribs

Load Ratings: Dynamic ~83.0 kN | Static ~86.0 kN

Material: High-quality alloy steel with pressed steel cage

Radial Internal Clearance: CN (Normal)

Precision Rating: ISO Class 0

Speed Limits: ~6,800 rpm (grease) | ~8,100 rpm (oil)

Temperature Range: –40 °C to +120 °C

Weight: ~0.80 kg

Applications: Gearboxes, compressors, pumps, electric motors, and heavy industrial machinery

Product Description

The NTN NU 212 Cylindrical Roller Bearing is engineered for high radial load capacity and excellent performance at high speeds. Its NU-type configuration features a separable inner ring and an outer ring with two fixed ribs, allowing axial displacement of the shaft to compensate for thermal expansion. Made from premium-quality alloy steel and equipped with a pressed steel cage, this bearing delivers strength, durability, and long service life in demanding industrial applications.
