Bearing 7319 B SKF

Key Specifications

Bore (d): 95 mm

Outside Diameter (D): 200 mm

Width (B): 45 mm

Contact Angle: 40°

Basic Dynamic Load Rating (approx): 180 kN

Basic Static Load Rating (approx): 163 kN

Limiting Speed: ~ 4 300 rpm (according to one listing)

---

⚙ Features & Advantages

✔ Combined Radial and Axial Load Support: The angular contact geometry allows the bearing to carry significant axial thrust in one direction in addition to heavy radial loads.

✔ High Precision Design: Manufactured by SKF, ensuring reliable performance, minimal vibration and low maintenance.

✔ High Axial Capacity: With a 40° contact angle, the axial load capacity is enhanced compared to standard angular contact bearings with smaller angles.

✔ Robust Dimensions: At 95×200×45 mm, this bearing offers substantial size and load-carrying capacity for heavy-duty applications.

✔ Versatile Use: Suitable for many industrial machines where shaft location in the axial direction is required and radial loads are high.

---

Typical Applications

Machine tool spindles and high-precision rotating equipment

Gearboxes and transmission systems needing axial location and radial support

Pumps, compressors and large motors where axial thrust is present

Heavy industrial equipment (mining, metallurgy, etc.) subject to combined loads

---

Specification / Ordering Notes

Confirm the exact variant suffix (e.g., “7319 B”, “7319 BECBM”, “7319 BECBY”) as cage type, seating variant or clearance grading may differ. Motion+1

Ensure the correct axial load direction is used (single-direction thrust load inherent in single-row angular contact bearings).

Check internal clearance and preload options—depending on mounting and operating conditions a paired set or duplex arrangement may be needed for bidirectional axial loads.

Ensure lubrication regime (grease or oil) is appropriate for speed, load and temperature conditions—bearing limiting speed is ~4–5 k rpm in typical configuration.
