Himel DC Miniature Circuit Breaker HDB3WZ2C – 2 Pole, 32A,
,

Himel DC Miniature Circuit Breaker HDB3WZ2C – 2 Pole, 32A,

₨ 3,200

Availability: 50 in stock

SKU: 0512 Categories: , Brand:

Key Features

  • Rated Current: 32 Ampere
  • Pole Configuration: 2 Pole (2P)
  • Rated Operational Voltage: 500V DC
  • Tripping Curve: C Curve
  • Breaking Capacity: 6kA
  • Protection Functions: Overload and short-circuit protection
  • Mounting Type: 35mm DIN Rail
  • Impulse Withstand Voltage: 6kV
  • Mechanical Durability: Up to 20,000 operating cycles
  • Electrical Durability: Up to 3,000 operating cycles
  • Terminal Capacity: Up to 25 mm² conductors
  • IP Rating: IP20
  • Standards Compliance: IEC 60947-2, CE, and CB certified.

Typical Applications

  • Solar PV string protection
  • Battery energy storage systems
  • DC combiner boxes
  • Inverter installations
  • Industrial DC control circuits
  • Renewable energy projects

Himel DC Miniature Circuit Breaker HDB3WZ2C – 2 Pole, 32A, 6kA

The Himel HDB3WZ2C DC Miniature Circuit Breaker (MCB) is specifically designed for direct current (DC) applications, providing dependable protection against overloads and short circuits. With a 2-pole configuration, it safely isolates both positive and negative conductors, making it ideal for solar PV systems, battery storage installations, and DC distribution networks. Its compact design and DIN rail mounting ensure easy installation and reliable operation.
